Description
.High efficiency gluing machine, operating speed can reach 11 rows/min
2.Can choose single side gluing,double sides gluing or none gluing.
3.Can parallel or nest gluing.
4.Continuous or intermittent gluing is optional
5.Special protective device,Easy to operate and maintain
6.Servo conveying mattress,accurate size;
7.Mattress adjustment is convenient,just enter the width of the mattress,row number system automatically calculate the conveying distance,more simple and fast.
8.Automatic round trip cutting function saves time;
9.CNC platform lifting saves time and effort;
10.Built-in sofa bag function,can do up to 5 bags,improve efficiency.
11.Entrance photoelectric induction,more safer.
Machine Specification
|
Model |
SN-PSA11 |
|
Max Mattress Width |
2200MM |
|
Spring Height |
60-350MM |
|
Spring Diameter |
φ37-75MM |
|
Glue Tank |
10L |
|
Hot Adhesive System |
Meltec or Robatech |
|
Capacity |
6-11 Rows/MIN |
|
Power |
6.5KW |
|
Weight |
3000KG |
Warranty
● We provide one year quality guarantee for our machine and electrical component from the date customer received the machine.
● We provide installation video and user manual for all of our machine.
● We can take video to help you completely solving any problems you encounter during installation and daily use,because we have all machine ready in our exhibition room.
● Except one year warranty, we provide lifelong free guidance for our product.
